Technical Features
·Certificate: UL
| ·Standards: |
Flame Propagation:EN 50200:2015 Class PH120 |
|
Acidity: EN/IEC 60754-1:2014
Smoke Density: EN/IEC 61034-2:2005+A1:2013 |
| ·Electrial Data: |
Insulation Resistance @ 20°C: >200 M Ohm*Km |
|
Test Voltage Core-Core/ Core-Screen: 2000V/2000V
Mutual Capacitance: <150 nf/km
Operating Voltage: 300/500V |
| ·Temperature Range: |
During Operation: -40℃ up to +90℃ |
|
During Installation：-5°C up to +50°C |
·Identification of Cores: 2 Cores, 3 Cores, 4 Cores.
