Horizontal Sidewall Fire Sprinkler Quick Response K5.6

Technical Features

·Certificates: FM, UL
·Response: Standard and Quick
·Discharge Coefficient: K=5.6 (80)
·Temperature Rating/ Color/ Classification:
135°F (57°C)/ Orange / Ordinary
155°F (68°C)/Red/ Ordinary
175°F (79°C)/ Yellow /Intermediate
200°F (93°C)/Green/Intermediate
286°F (141°C) / Blue/ High
·Nominal Thread Size: 1/2″ NPT/ 1/2″ BSPT
·Maxmum Working Pressure: 175psi(12 Bar).
·Testing Pressure: 7psi(0.5 Bar).
·Minimum Operating Pressure: 500psi(35 Bar).
·Temperature(℃): -30℃~+60℃
·Optional Surface Finishing: Brass, White Coating and Chrome.
